FAB PAVE™ S20 – Sealed & Locking FAB PAVE™ Recessed
External

The FAB PAVE™ S20 is a recessed cover designed to prevent egress of odours and the ingress of surface water. the product is fitted with a neoprene gasket as standard and a double neoprene gasket for further assurance.

  • Suitable for external use, allows for non-structural infill, ideal in paved environments.
  • Typical applications are retail parks and public areas of high prestige.
  • Designed to blend in aesthetically with the surrounding area.

Facta loading classes

AAA B D
Product Image
Product Thumbnail Image

Technical Details

  • Manufactured from S275J2 mild steel
  • Hot-dip galvanized 70μm minimum coating according to ISO1461
  • Neoprene sealed to provide an airtight seal
  • Robust keyway with small visible footprint which incorporates an M12 threaded locking and lifting point
  • Cover sides tapered to facilitate easy removal of cover from frame
  • Bolt fixing provision to ensure maximum performance
  • For more info, see our FACTA FAQ

Options Available

  •  Depths from 60mm to 150mm in tray (loading dependent)
  • Hot-dip galvanized coating 100μm or 140μm
  • Stainless steel (304 or 316)
  • Identification marking
